Description
Alfagomma C12243360-1212 60 Deg O-Ring Flange SAE J518 Code 61 Solid Bent Tube, AlfaCrimp One-Piece Fitting
- Brand: Alfagomma
- Thread Type: SAE Code 61 Flange
- Material: Steel
- Max. Working Pressure: 5000 PSI
- Weight Each: 0.704 lbs
- For Use with these Hoses: AT3K, FXP2, R1AT, R2AT
- Hose Dash Size: 12
- Hose Size: 0.75", 19.00 mm
- Cut-Off Factor (C): 86.0 mm
- Drop (D): 37.0 mm
- Flange Size (A): 1.50", 38.1 mm
- Ferrule Type: Non Skive
- Hose Type: 1 or 2 Wire Braid
- Connection Type: Flange
- Configuration: 60Deg Flange
- Nut Type: Solid
- R5 Hose: 5/8
